Fuses Usage
F4
Heated
Seats (If Equipped)
F5
Driver Door Switches
(Outside Rearview Mirror/
Charge Port Door
Release/Refuel Request/
Driver Window Switch)
F6
Fuel (Diurnal Valve and
Evap. Leak Check
Module)
F7
Accessory Power Module
Cooling Fan
F8
Amplifier
(If Equipped)
F9 Empty
Fuses Usage
F10
Regulated Voltage
Control/Ultrasonic Front
and Rear Parking Assist
(If Equipped)
F11 Horn
F12 Rear Power Windows
F13 Electric Parking Brake
F14 Rear Defog (Upper Grid)
F15 Empty
F16 Hatch Release
F17 Empty
F18 Empty
Relays Usage
R1
Rear Defog
(Upper Grid)
R2 Hatch Release
R3 Empty
R4 Empty
R5 Empty
R6 Empty
R7 Empty
R8 Horn
Diodes Usage
DIODE Empty
