Chevrolet Volt 2016 - Page 258

Chevrolet VOLT Owner Manual (GMNA-Localizing-U.S/Canada/Mexico-
9159388) - 2016 - crc - 10/21/15
Vehicle Care 257
Fuses Usage
F43 –
F44 Voltage current
temperature module
run/Crank
F45 Heated steering
wheel
F46 Vehicle integration
control module run/
Crank
F47 –
F48 –
F49 –
F50 –
F51 –
F52 Engine control
module/Traction
power inverter
module
F53 Left cooling fan
F54 Right cooling fan
F55 Electric pump
F56 –
F57 –
Relays Usage
K01 –
K02 –
K03 Engine control
module
K04 –
K05 –
K06 –
K07 –
K08 –
K09 –
K10 –
K11 –
K12 High-beam
headlamps
K13 –
K14 Run/Crank
K15 Rear window
defogger
K16 Horn PCB relay
K17 –
K18 –
Relays Usage
K19 Coolant pump PCB
relay
K20 –
K21 –
K22 Front washer
K23 –
