260 Vehicle Care
A fuse puller is in the engine
compartment fuse block.
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.
Fuses Usage
F1 –
F2 –
F3 –
F4 HVAC blower
F5 Body control
module 2
F6 –
F7 –
F8 Body control
module 3
F9 Fuel power pump
module
F10 –
F11 –
F12 –
F13 –
F14 –
Fuses Usage
F15 –
F16 –
F17 Data link connector
F18 Body control
module 7
F19 Cluster
F20 Body control
module 1
F21 Body control
module 4
F22 Body control
module 6
F23 OnStar
F24 Airbag
F25 Display
F26 Infotainment
F27 –
F28 –
F29 Overhead console
F30 Radio
F31 Steering wheel
controls
Fuses Usage
F32 Body control
module 8
F33 HVAC/Integrated
light solar sensor
F34 Passive entry/
Passive start
F35 Rear closure
F36 Charger
F37 –
F38 –
F39 –
F40 –
F41 –
F42 –
Circuit
Breakers
Usage
CB1 Front auxiliary power
outlet
CB2 Rear auxiliary power
outlet
