Chicago Pneumatic CP7901 - Page 2

L
Fig. 1
Fig. 2
Air Diagram:
* To see in Fig.2 for details.
A
Model
Strike
Frequency
Stroke Overall Length Weight
Air
Consumption
@load
Air
Inlet
Inner
Hose
Dia.
Sound
Pressure
LpA
Sound
Power
LwA
Vibrations
ahd K
1 3 5 6 7 8 9 10 11 12
bpm [mm] [inch] [mm] [inch] [Kg] [lb] [Nl/s] [SCFM] [inch] [mm] [inch] [dB(A)] [dB(A)]
[m/s²] [m/s²]
CP7900 10000 10 3/8 216 8.5 0.59 1.3 2.6 5.5 1/4 10 3/8 82 93
19.6 5.2
CP7901 10000 25 1 229 9 0.86 1.9 2.6 5.5 1/4 10 3/8 78 89
<2.5
CP9881 5500 25 1 268 10.5 1 2.2 3.1 6.7 1/4 10 3/8 81 92
<2.5
CP9705 12000 5 0.2 204 8.03 0.56 1.23 2.8 6 1/4 10 3/8 73 84
5 3
CP9710 8000 10 0.4 250 9.84 0.59 1.3 2.8 6 1/4 10 3/8 63 74
5 3
