2
Pull the FABRIC around the Harness Adjuster Strap
Cover.
Note: The plastic Harness Adjuster Strap Cover is
NOT removable.
12
While pulling back on the seat pad, lift up to unhook
the Fabric Plastic Tab from the clip on the top of the
Carrier. Rocking the fabric side to side may help.
13
Remove the seat pad from the Carrier, Making sure
to gently guide the Seat Pad around the Head Rest. Push
the Comfort Kit pads through the slots in the seat pad and
remove the Comfort Kit.
WARNING - NEVER use Child Restraint without the seat pad.
14
Flip the Carrier over and remove BOTH Shoulder Harness
Straps from the Splitter Plate. Then flip the Carrier upright
and pull the Shoulder Harness Straps to front of Carrier.
7
Adjust Head Rest into the highest position. Then pull
down on and un-tuck the bottom fabric pocket from the
Head Rest Back Plate.
8
Remove the Head Rest fabric. Then adjust the Head
Rest to the lowest position, making sure that the Head
Rest Back Plate slides BEHIND the Seat Fabric.
9
Place the Carrier on its side and unhook the Fabric
Straps, located just below the Handle’s rotating hinge.
Repeat for the other side.
10
Un-fold the Fabric Plastic Tabs from the Foot of the
Carrier.
11
To Next Page
