21
each wash.
WARNING: When covering or removing the cover of the product,
take care when handling the fabric parts so as to avoid accidental
tears or damage.
WARNING: The fabric part of the foldable side can be removed par-
tially to allow the side to be removed when the product is used in
cot configuration (see point 26).
REMOVING THE FABRIC FROM THE PRODUCT
27. Open the zippers along the perimeter of the base “H4” and then
the vertical external zipper “H5” and internal vertical zipper “H6”.
28. Release the internal upper snap buttons “H2” and external snap
buttons “H3”.
29. Remove the mattress.
30. Release the nine snap buttons “H1” on the bottom.
31. Release the upper frame “B” from the frame for height adjust-
ment “F”, operating on the pins of the upper frame “B”.
32. Remove the upper frame “B” from the fabric “H”.
33. You can now remove the lining.
REMOVING THE MATTRESS COVER
34. Open the lower Velcro strap “E1” (Fig. 40), remove the panel (Fig.
41) and the lower mattress “E3” (Fig. 42).
35. Open the upper Velcro strap “E2” (Fig. 43) and remove the upper
mattress “E4” (Fig. 44).
Follow the steps above in reverse order to cover the mattress again.
DISASSEMBLING THE PRODUCT
Once the fabric covers and legs have been removed from product,
the product can be completely disassembled by following steps 1
to 6 in reverse order.
WARRANTY
The product is guaranteed against any conformity defect in normal
conditions of use as described in the instructions. The warranty shall
not therefore apply in the case of damage caused by improper use,
wear or accidental events. For the duration of the warranty on con-
formity defects please refer to the specific provisions of applicable
national laws in the country of pur chase, where appropriate.
