Chicco Top Digital Audio - Technical Specifications; System, Unit, and Adapter Specs

18 19
in the home and the presence of metallic
structures, external and internal interference/
electromagnetic fields, concrete walls or between
rooms on different floors or because batteries are
not fully charged, etc.).
Baby unit
Power:
Internal: TWO 1.5V AAA/LR03 ALKALINE
BATTERIES
External: via 100-240V~ 50/60Hz /6V
500mA mains switching adapter
Transmission:
- Transmission frequency band: 1880-1900 MHz
- Signal strength: 250mW max
Parent unit
Power:
Internal: 3.7V 800mAh LITHIUM-ION BATTERY
External: via 100-240V~ 50/60Hz /6V
500mA mains switching adapter
Lithium-ion battery charging via 100-240V ~
50/60Hz /6V 500mA mains switching
adapter
Reception:
- Transmission frequency band: 1880-1900 MHz
- Signal strength: 250mW max
Mains adapter
Mod. S003IV0600050
INPUT: 100-240V ~ 50/60Hz 150mA
OUTPUT: 6V 500mA
Plug polarity:
Made in China
Lithium-ion battery
Mod. MB1022 (ICP46/34/46)
Nominal capacity: 800mAh (2.96Wh)
Nominal voltage: 3.7V
Lithium batteries gives best performance when
used at normal room temperature (20°C±5°C)
Made in China
SYMBOLS KEY
monophase alternate current
direct current
for indoor use only
Class II - double insulation
equipment
Conforms to applicable EC
directives and subsequent
amendments
ATTENTION. Read the
instructions for use
