CMV MINI VRF System - Outdoor Unit
4 Electric characteristics
Model
Outdoor Unit
Power Supply
Compressor
Fan Motor.
Hz
Voltage
Min.
Max.
TOC
MFC
LRC
Output
FLC
CMV-V100W/ZR1
50
380~415
342
437
25
20
/
0.1*2
1.6
CMV-V125W/ZR1
50
380~415
342
437
25
20
/
0.1*2
1.6
CMV-V140W/ZR1
50
380~415
342
437
25
20
/
0.1*2
1.6
CMV-V160W/ZR1
50
380~415
342
437
25
20
/
0.1*2
1.6
CMV-V100W/YR1
60
380~415
342
437
25
20
/
0.1*2
1.6
CMV-V125W/YR1
60
380~415
342
437
25
20
/
0.1*2
1.6
CMV-V140W/YR1
60
380~415
342
437
25
20
/
0.1*2
1.6
CMV-V160W/YR1
60
380~415
342
437
25
20
/
0.1*2
1.6
Remark:
 Min.: Permitted minimum operating voltage, lower than this value may damage the system
 Max.: Permitted maximum operating voltage, higher than this value may damage the system
 TOC: Total Over-Current (A)
 MFC: Maximum Fuse Current (A)
 LRC: Locked Rotor Current (A)
 FLC: Full Load Current (A)
 Output: Fan motor rated power Output (kW)
Notes:
 RLC is based on the following conditions, indoor temperature 27˚C DB/19˚C WB, outdoor temperature 35˚C DB
 TOC means the total value of each Over-Current set.
 MSC means the Maximum current during the starting of compressor.
 Maximum allowable voltage variation between phases is 2%
 Selection wire size based on the larger value of MC or TOC
 MFC is used to select the circuit breaker and the ground fault circuit interrupter (earth circuit breaker).
