CMV MINI VRF System - Outdoor Unit
Table 2.
Item
Symbol
Name
CMV-V140W/ZR1
CMV-V140W/YR1
CMV-V160W/ZR1
CMV-V160W/YR1
Compressor
Inverter
Inverter compressor
TNB306FPNMC
LNB42FSAMC
Compressor
Starting current
/
/
Safety OLP
CCH
Crank case heater
35W
Motor and
security devices
Motor
Fan motor
Model
DR-380-100-8
DR-380-100-8
Output
power
100W*2
100W*2
Safety
On
120℃
thermostat
Off
/
HP
High pressure switch
OFF:44(±1)kg/cm
2
ON:32(±1)kg/cm
2
LP
Low pressure switch
OFF:1.4(±1)kg/cm
2
ON:3.0(±1)kg/cm
2
Temperature
sensor
T3,T4
Temperature sensor
25°C=5KΩ
(condenser outlet/ambient
temperature)
Discharge
thermostat
Thermostat (Inverter
discharge)
BW120°C ON:120°C OFF:90°C
Functional parts
PMV
Electronic expansion valve
UKV-32D210 (Foshan Hualu)
4-W/V
4-way valve
TB-STF-B01-R410A (Foshan Hualu)
SV
Solenoid valve
FDF6A42. (Zhejiang Sanhua)
