2 CCH01718
STEP 2 - DIAGRAM 2: ATTACH STABILIZER BAR
Attach Stabilizer Bar
JJ
JJ
J to Headboard N &
Footboard O as shown. Also refer to DIAGRAM
5
.
Place a Combo/Phillips Machine Screw A into
top receiving bushing
for installing Stabilizer Bar
JJ
JJ
J
located in ends
NN
NN
N & O as shown, leave
screws extended - do not tighten at this time.
Place the keyhole
(top hole in each end of Stabi-
lizer Bar
JJ
JJ
J
), over top extended screws A as
shown.
Locate the bottom Combo/Phillips
Machine Screws
AA
AA
A into the lower receiving holes
in each end of the Stabilizer Bar
JJ
JJ
J and into
receiving bushings located in ends
NN
NN
N &
OO
OO
O.
Tighten all four Machine Screws
AA
AA
A securely at
this time. Repeat this process for the remaining
Stabilizer Bar J and four Machine Screws A.
Insure all (8) Machine Screws A are tightened
securely before continuing with next step.
STEP 3 - DIAGRAM 3: ATTACH GATE SHOES
Attach Gate Shoes
CC
CC
C to lower
rail
(inside)
of Dropsides P &
Q as shown and affix with
Combo/Phillips Wood Screws
EE
EE
E.
Note: Gate Shoe Patent
No. will be visible when Gate
Shoes
CC
CC
C are mounted. Tighten
Combo/Phillips Wood Screws
EE
EE
E securely. Note: When dis-
assembling crib in the future,
DO NOT REMOVE THE GATE
SHOES OR ANY OTHER
HARDWARE ITEM ATTACHED
WITH COMBO/PHILLIPS
WOOD SCREWS
EE
EE
E.
STEP 4 - DIAGRAM 4: INSTALL SPRING
Locate "Tabs" on Crib Spring
RR
RR
R and
rotate Tabs upward. Position the (4)
Tabs attached to ends of Crib Spring
RR
RR
R
to mount to selected position in the 4-
Position Spring Brackets D mounted
on ends
NN
NN
N and
OO
OO
O. Install a Hexhead
Machine Screw B through the (4) Crib
Spring Tabs and into a receiving hole
in each 4-Position Spring Bracket
DD
DD
D
then tighten securely with enclosed
Hex Wrench F. Follow the same
procedure when changing spring height
at a later date. Check Hexhead Ma-
chine Screws
BB
BB
B periodically and tighten
if needed.
A Extended
Footlatch
Keyhole
I
N
or O
J
A
Crib Rods K will be
inserted thru these holes in
Step 5 - Diagram 5.
P or Q
C
E
N or O
R
F
B
D
Tab
Tab
Top Surface
To Relocate Crib
Spring
RR
RR
R, Remove
Hexhead Machine
Screw
B B
B B
B with Hex
Wrench
FF
FF
F.
NOTE: Mount all 4 "Tabs" on Crib
Spring R at the same vertical
mattress position.
E
