CHINT DTSU666-CT User Manual

DTSU666 series and DSSU666 series
three phase electronic energy meter
ZTY0.464.1448
User manual
Page 13, Total 21
Electricity data on the secondary side
2000H
Uab
Three phase line voltage data, Unit V(×0.1V)
float
2
R
2002H
Ubc
float
2
R
2004H
Uca
float
2
R
2006H
Ua
Three phase voltage data, Unit V(×0.1V)
(Invalid for three phase three wire)
float
2
R
2008H
Ub
float
2
R
200AH
Uc
float
2
R
200CH
Ia
Three phase current data, Unit A(×0.001A)
float
2
R
200EH
Ib
float
2
R
2010H
Ic
float
2
R
2012H
Pt
Combined active power, Unit W(×0.1W)
float
2
R
2014H
Pa
A phase active power, Unit W(×0.1W)
float
2
R
2016H
Pb
B phase active power, Unit W(×0.1W)
(Invalid for three phase three wire)
float
2
R
2018H
Pc
C phase active power, Unit W(×0.1W)
float
2
R
201AH
Qt
Combined reactive power, Unit var(×0.1var)
float
2
R
201CH
Qa
A phase reactive power, Unit var(×0.1var)
float
2
R
201EH
Qb
B phase reactive power, Unit var(×0.1var)
(Invalid for three phase three wire)
float
2
R
2020H
Qc
C phase reactive power, Unit var(×0.1var)
float
2
R
202AH
PFt
Combined power factor(forward number：
inductive，reverse number：capacitive) (×0.001)
float
2
R
202CH
PFa
A phase power factor(forward number：
inductive，reverse number：capacitive)
(Invalid for three phase three wire) (×0.001)
float
2
R
202EH
PFb
B phase power factor(forward number：
inductive，reverse number：capacitive)
(Invalid for three phase three wire) (×0.001)
float
2
R
2030H
PFc
C phase power factor(forward number：
inductive，reverse number：capacitive)
(Invalid for three phase three wire) (×0.001)
float
2
R
2044H
Freq
Frequency, Unit Hz(×0.01Hz)
float
2
R
Power secondary side data
101EH
ImpEp
（current）Total Forward active energy(kWh)
float
2
R
