NXCC series contactors for capacitor switching (hereinsafter referred to
as contactor) is mainly used in power systems with AC 50Hz or 60Hz,
rated operating voltage up to 690V. It is used to connect and disconnect
shunt capacitors with the aim to improve power factor.
Use Purpose
2
Main Technical Parameters
Table 1 Installation and operation conditions
Model
NXCC-25 NXCC-32 NXCC-43 NXCC-63 NXCC-95 NXCC-115 NXCC-150 NXCC-170
Rated impulse withstand
voltage Uimp( kV)
6
Rated limited short-circuit
current Iq(kA)
50(400V)
Rated operating voltage
Ue (V)
220/230、380/400、660/690
Inrush current suppression
capability
20Ie
Operating frequency
Time/hour
120
Electrical life AC-6b
（×10
4
times）
15
Mechanical life
（×10
4
times）
100
On-load Factor
40%
Pole impedance(Ω) ≤0.05
Arcing distance （mm） 10 12 15
Type of Coordination Type “2” coordination
Model of matching fuse
gG25 gG32 gG50 gG63 gG100 gG125 gG160 gG200
Rated current of Fuse(A)
25 32 50 63 100 125 160 200
Auxiliary Circuit
Parameters
Model of matching fuse:gG10；Ith：10A；
AC-15：Ue/Ie：AC220V/230V/2.7A，AC380V/400V/1.5A；DC-13：Ue/Ie：DC220V/0.3A
The limiting working temperature is -35℃~+70℃,the normal working temperature is -5℃
~+40℃,and the average temperature within 24 hours is not more than +35℃.If it is not in the
normal operating temperature range,the capacity reduction shall be considered.
Relative humidity should not exceed 50% at temperature up to +70℃, higher relative humidity is
allowed under lower temperature, for example up to 90% at +20℃. User should take special
measures against condensation due to temperature change.
The applicable temperature range for transportation and storage conditions is between -25℃ and
+55℃, which can reach +70℃within a short-time (24h). The storage place shall be ventilated and
dry, and shall not be attacked by rain, snow and shall not be exposed to direct sunlight.
8 hour duty system,uninterrupted duty system,intermittent duty system(Loag factor 40%),short
term duty system
AC coil
power
Pick-
up(VA)
≤70 ≤210 ≤300 ≤1000
Hold (VA)
≤9.5 ≤11.4 ≤36.6 ≤91.2
Rated duty system
Operation range Pick-up voltage: 85%Us~110%Us Release voltage:20%Us~75%Us
Ambient temp(℃)
Humidity
Altitude Not higher than 2000m
Pollution class Class 3
Installation conditions
The angle between the installation surface and the vertical surface should not be greater than ±5°.
Transportation & Storage
Conditions
