Chipolino HUG - Assembly Guide

3
Tools needed: screwdriver, used to insert and remove batteries. To complete assembly of swing you
do no need to use tools.
The assembly actions are numbered from 1 to 7. Use their descriptions below along with the illustration
with the same number.
1 – ASSEMBLY OF LEFT AND RIGHT SWINING MECHANISMS TO THE LEFT AND RIGHT
SUPPORTS
2 – SEAT ASSEMBLY
Insert both endings of the seat into the axis of the swinging mechanisms. Fix with the button and cover.
Make sure the seat is securely xed as trying to pull the endings from the axis of swinging mechanisms.
3 – ATTACHING THE MOBILE TOY
After you x the mobile toy, make sure it can spin.
4 – RESTRAINT SYSTEM (SAFETY HARNESS)
4-1 Securing the child with safety harness.
To unlock the harness press the central button of buckle.
4-2 Adjustment the length of harness.
Note: Adjust the belts so that they t well the child and are not twisted.
CAUTION! Periodically check to ensure that the seat belt is securely attached to the stroller frame as
well as securely fastened. The belts should not be worn or torn, and plastic buckles and fasteners must
be sturdy, free of damage and secure.
5 – MOBILE TOY
Mobile toy can spin in direction shown on the gure. This makes easier placing and taking out the child
from the swing.
6 – BACKREST ADJUSTMENT
Pull the buttons and set the backrest upwards/downwards until you reach the required position.
7 – SWING FOLDING
7a – Fold the swing;
7b – Press the folding buttons and fold the tubes of both swinging mechanisms.
IMPORTANT! Follow exactly the guidelines and the sequence of steps for product assembly and use
which you will nd in the gures in this manual.
CAUTION! After completing each step, check that xing is secure!
CAUTION! Fixing in certain position is most of the times accompanied with a click!
CAUTION! Make sure all pins have shown through the openings.
ASSEMBLY GUIDE
