Cavity
Cartridge
Fuse
Mini
Fuse
Description
22 —
10 Amp
Red
Ignition Run – Cli-
mate Controls/Hot
Cupholder – If
Equipped
23 —
15 Amp
Lt. Blue
Auto Shutdown
(ASD) Relay 3
24 —
25 Amp
Natural
Sunroof – If
Equipped
25 —
10 Amp
Red
Ignition Run —
Heated Mirrors - If
Equipped
26 —
15 Amp
Lt. Blue
Auto Shutdown
(ASD) Relay 2
Cavity
Cartridge
Fuse
Mini
Fuse
Description
27 —
10 Amp
Red
Ignition Run – Occu-
pant Classification
Module (OCM)/
Occupant Restraint
Controller (ORC)
28 —
10 Amp
Red
Ignition Run — Oc-
cupant Classification
Module (OCM)/
Occupant Restraint
Controller (ORC)
29 — —
Hot Car (No Fuse
Required)
30 —
20 Amp
Yellow
Ignition Run –
Heated Seats – If
Equipped
31 —
10 Amp
Red
Headlamp Washer –
If Equipped
7
MAINTAINING YOUR VEHICLE 431
