SERVICING AND MAINTENANCE 255
7 40 Amp Green – Exterior Lighting #2
8 30 Amp Pink – Interior Lighting
9 40 Amp Green – Power Locks
10 30 Amp Pink – Driver Door Control Module
11 30 Amp Pink – Passenger Door Control Module
12 – 20 Amp Yellow
Dual USB Center Console Rear/
+12 Volt Power Outlet IP – If
Equipped / IP APO – If Equipped
15 40 Amp Green – HVAC Blower
16 20 Amp Blue – Left Spot Lamp – Police
17 20 Amp Blue – Right Spot Lamp – Police
18 30 Amp Pink – Mod Network Interface – Police
19 – – Fuse – Spare
20 – – Fuse – Spare
21 30 Amp Pink – Fuel Pump (Non 6.2L SRT)
22 – 5 Amp Tan Cyber Gateway Module
23 – 10 Amp Red
Fuel Door – If Equipped/Diagnostic
Port
24 – 10 Amp Red Integrated Center Stack
25 – 10 Amp Red Tire Pressure Monitor System
Cavity Cartridge Fuse Mini-Fuse Description
8
