256 SERVICING AND MAINTENANCE
26 – 15 Amp Blue
Cygnus Transmission Module
(Charger Non - Police/300)
27 – 25 Amp Clear Amplifier – If Equipped
31 – 25 Amp Breaker Power Seats – If Equipped
32 – 15 Amp Blue HVAC Module/Cluster
33 – 15 Amp Blue
Ignition Switch/RF Hub Module/
Steering Column Lock (300) – If
Equipped / Remote Start – If
Equipped
34 – 10 Amp Red
Steering Column Module/Clock
(300)
35 – 5 Amp Tan Battery Sensor
36 – 15 Amp Blue
Electronic Exhaust Valve – If
Equipped
37 – 20 Amp Yellow Radio
38 – 20 Amp Yellow Media Hub / Console APO
42 30 Amp Pink – Rear Defrost
43 – 20 Amp Yellow
Rear Heated Seats – If Equipped /
Heated Steering Wheel – If
Equipped
44 – 10 Amp Red
Park Assist / Blind Spot / Rear
View Camera
Cavity Cartridge Fuse Mini-Fuse Description
21_LX_OM_EN_USC_t.book Page 256
