SERVICING AND MAINTENANCE 257
45 – 15 Amp Blue
Cluster / Rearview Mirror / Lane
Departure
46 – – Fuse – Spare
47 – 10 Amp Red
Adaptive Front Lighting / Day Time
Running Lamps – If Equipped
49 – – Fuse – Spare
50 – – Fuse – Spare
51 – 20 Amp Yellow
Front Heated / Vented Seats – If
Equipped
52 – 10 Amp Red
Heated/Cooled Cup Holders/Rear
Heated Seat Switches – If
Equipped
53 – 10 Amp Red
HVAC Module/In Vehicle
Temperature Sensor
54 – – Fuse – Spare
55 – – Fuse – Spare
56 – – Fuse – Spare
57 – – Fuse – Spare
58 – 10 Amp Red Airbag Module
59 – 20 Amp Yellow Adjustable Pedals – Police
60 – – Fuse – Spare
61 – – Fuse – Spare
Cavity Cartridge Fuse Mini-Fuse Description
8
21_LX_OM_EN_USC_t.book Page 257
