IN CASE OF EMERGENCY 197
7 20 Amp Blue – Police Ignition Run / ACC #1
8 50 Amp Red / 20 Amp Blue – Radiator Fan (6.2L Supercharged) / Police Ignition Run / ACC # 2
9 – 20 Amp Yellow All-Wheel Drive Module – If Equipped
10 – 10 Amp Red Intrusion MOD (300) – If Equipped / Under Hood Lamp – Police
11 – 20 Amp Yellow Horns
12 – 10 Amp Red Air Conditioning Clutch
13 – – Fuse – Spare
14 – – Fuse – Spare
15 – 20 Amp Yellow Left HID – If Equipped
16 – 20 Amp Yellow Right HID – If Equipped
18 50 Amp Red – Radiator Fan – (Non 6.2L Supercharged)
19 50 Amp Red – Electric Power Steering #2 – If Equipped
20 30 Amp Pink – Wiper Motor
21 30 Amp Pink
20 Amp Blue – Police
– Headlamp Washers – If Equipped
Police Bat Feed #2
22 40 Amp Green / 20 Amp
Blue – Police
– Engine Cooling Pump (6.2L Supercharged) / Police Bat Feed # 3
23 20 Amp Blue – Police Bat Feed # 1
24 50 Amp Red / 20 Amp Blue – Radiator Fan (6.2L Supercharged) / Police Ignition Run/ACC Feed # 3
28 – – Fuse – Spare
Cavity Cartridge Fuse
Mini-Fuse
Description
6
