198 IN CASE OF EMERGENCY
29 – 15 Amp Blue Transmission Control Module (Challenger / Charger Police)
30 – – Fuse – Spare
31 – 25 Amp Clear Engine Module
32 – – Fuse – Spare
33 – – Fuse – Spare
34 – 25 Amp Clear ASD Feed #1
35 – 20 Amp Yellow ASD Feed #2
36 – 10 Amp Red Anti-Lock Brake Module / Steering Column Lock Module (300 if
equipped)
37 – 10 Amp Red Engine Controller
38 – 10 Amp Red Airbag Module
39 – 10 Amp Red A/C Clutch / EPS – If Equipped / Vacuum Pump – If Equipped
48 – 10 Amp Red AWD Module / Front Axle Disconnect – If Equipped
49 – – Fuse – Spare
50 – – Fuse – Spare
51 – 20 Amp Yellow Vacuum Pump – If Equipped
52 – 5 Amp Tan Adaptive Cruise – If Equipped
53 – – Fuse – Spare
Cavity Cartridge Fuse
Mini-Fuse
Description
