IN CASE OF EMERGENCY 201
31 – 25 Amp Breaker Power Seats – If Equipped
32 – 15 Amp Blue HVAC Module/Cluster
33 – 15 Amp Blue Ignition Switch/RF Hub Module/Steering Column Lock
(300) – If Equipped / Remote Start – If Equipped
34 – 10 Amp Red Steering Column Module/Clock (300)
35 – 5 Amp Tan Battery Sensor
36 – 15 Amp Blue Electronic Exhaust Valve – If Equipped
37 – 20 Amp Yellow Radio
38 – 20 Amp Yellow Media Hub / Console APO
40 30 Amp Pink – Fuel Pump (6.2L SRT – If Equipped)
41 30 Amp Pink – Fuel Pump (6.2L SRT – If Equipped)
42 30 Amp Pink – Rear Defrost
43 – 20 Amp Yellow Rear Heated Seats – If Equipped / Heated Steering
Wheel – If Equipped
44 – 10 Amp Red Park Assist / Blind Spot / Rear View Camera
45 – 15 Amp Blue Cluster / Rearview Mirror / Lane Departure
46 – – Fuse – Spare
47 – 10 Amp Red Adaptive Front Lighting / Day Time Running Lamps – If
Equipped
48 – 20 Amp Yellow Active Suspension – (6.4L)
49 – – Fuse – Spare
Cavity Cartridge Fuse Mini-Fuse Description
