202 IN CASE OF EMERGENCY
50 – – Fuse – Spare
51 – 20 Amp Yellow Front Heated / Vented Seats – If Equipped
52 – 10 Amp Red Heated/Cooled Cup Holders/Rear Heated Seat Switches
– If Equipped
53 – 10 Amp Red HVAC Module/In Vehicle Temperature Sensor
54 – – Fuse – Spare
55 – – Fuse – Spare
56 – – Fuse – Spare
57 – – Fuse – Spare
58 – 10 Amp Red Airbag Module
59 – 20 Amp Yellow Adjustable Pedals – Police
60 – – Fuse – Spare
61 – – Fuse – Spare
62 – – Fuse – Spare
63 – – Fuse – Spare
64 – 25 Amp Breaker Rear Windows (Charger/300)
65 – 10 Amp Red Airbag Module
66 – – Fuse – Spare
67 – 10 Amp Red Rain and Light Sensor / Sunroof / Inside RearView
Mirror / Police Run Acc Relay
68 – 10 Amp Red Rear USB Timer / Rear Sunshade – If Equipped
Cavity Cartridge Fuse Mini-Fuse Description
