Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
1 60 Amp
Yellow
— Ignition Off Draw (IOD)
Cavity 1 of the Rear
Power Distribution
Center contains a black
IOD fuse needed for
vehicle processing dur-
ing assembly. The ser-
vice replacement part is
a 60 Amp yellow car-
tridge fuse.
2 40 Amp
Green
— Integrated Power Mod-
ule (IPM)
3 ———
4 40 Amp
Green
— Integrated Power Mod-
ule (IPM)
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
5 30 Amp
Pink
— Heated Seats – If
Equipped
6 — 20 Amp
Yellow
Fuel Pump
7 — 20 Amp
Yellow
Sub Amp – If Equipped
8 — 15 Amp
Blue
Diagnostic Link Connec-
tor (DLC)/Wireless Con-
trol Module (WCM)/
Wireless Ignition Node
(WIN)
9 — 20 Amp
Yellow
Power Outlet
10———
11 * ———
402 MAINTAINING YOUR VEHICLE
