Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
12 * ———
13 * ———
14 — 10 Amp
Red
AC Heater Control/
Cluster/Security Mod-
ule – If Equipped
15———
16———
17 — 20 Amp
Yellow
Cluster
18 — 20 Amp
Yellow
Selectable Power Outlet
19 — 10 Amp
Red
Stop Lights
20———
21———
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
22———
23———
24———
25———
26———
27 — 10 Amp
Red
Occupant Restraint Con-
troller (ORC)
28 — 10 Amp
Red
Ignition Run
29 — 5 Amp
Orange
Cluster/Electronic Sta-
bility Program (ESP)/
Powertrain Control
Module (PCM)/Stop
Light Switch
7
MAINTAINING YOUR VEHICLE 403
