CIARRA CBCS6903 - Page 18

EN
Cleaning and Maintenance
4. Put the iron baffle back on the cooker hood and press the lock to the
left.
16
3. To replace the new LED light, press the LED into the LED mounting hole,
insert the plug into the corresponding position on the main board of
the circuit control box,close the cover of the circuit control box and
tighten the screws.
LED
cover
