4.2 - Pictograms
Heating coil Filter
Electric heater Electrics box
Cooling coil 6WHDPKXPLGL¿HU
Steam coil Stop-drop
$GLDEDWLFKXPLGL¿HU Fan
Discharge siphon $LUÀRZ
Sound attenuator &RLORXWOHWDUURZ
&RLOLQOHWDUURZ
FILTRES
EMPOUSSIERES
INFLAMMABLES
DANGER
D’INCENDIE
DIRTY FILTRES
ARE INFLAMMABLE
7028397.03
FIRE DANGER
Fire danger
Plate recovery unit Pressure tapping
Rotary heat exchanger
