2
INSTALL THE KEYPAD
Install front panel and front panel silicon pad,
make sure the latch bolt be contracte.
3
FIXING OF REAR PANEL
Pass the IC wire and the latch link bar to
mounting plate.
Use the screws as shown in the gure con-
nect rear panel xing plate with latch and
door.
Note: Please place the IC line as shown in
the gure to avoid the lock latch out of con-
trol.
