cinq Shift:R Tour - Attach Shift:R Box to Gearbox

2 Remove the original Pinion shifting unit with the factorytted rotary
handle according to the Pinion instructions.
The same three mounting bolts which attach the Pinion shift box
to the gearbox are used to attach the Shift:R Box to the gearbox.
Align the holes in the Shift:R Box to position the shift cables as straight
as possible. Tighten the bolts to 1.5 Nm.
1.5 Nm
