3 Install the cable housing. Measure and cut to length accordingly, then t
end caps to both ends. The upper cable coming from the Shift:R Box is
responsible for shifting into easier/slower gears, the lower one for shifting
into harder/faster gears. You can select your desired shifting logic by
routing the respective cable to the right or left shifter.
4a Shift:R Tour Make sure the cable adjusters are in a middle position before
you clamp the shifter cables at the levers to ensure adjustment range later.
Slightly pull the cable ends and tighten the cable fastener with an Allen key.
max. 2.5 Nm
slower
gear
faster
gear
19
