62
Now your LOOP ANTENNA is assembled,
put it on the mounting clamp.
The mounting clamp will be anchored to
the mast as shown in the picture.
Fix the antenna onto the
mounting clamp with the
bolts.
63
Connect the power cable from the
loop controller ATU to the cable from
the actuator. The connecting terminal
is equipped with an RF suppression
toroid.
Now you can proceed to the first turn on – page 75.
