60
After the piston-head is in place, install the fix
cap head hexagon socket drive screw with self-locking nut. Tighten the nut until it
reaches the surface of the isolated arm. Do not force it.
The picture shows the assembled
part.
61
Now connect the semi-loop junction
blade. Spread the anti-oxidant paste
before installing the retaining bolts.
Install the washers and bolts, then
tighten them with a wrench. Now
your LOOP ANTENNA is complete.
