10
Cisco 2811 and Cisco 2821 Integrated Services Router FIPS 140-2 Non Proprietary Security Policy
OL-8663-01
Cisco 2811 and Cisco 2821 Routers
The physical interfaces are separated into the logical interfaces from FIPS 140-2 as described in the
Table 8:
Table 7 Cisco 2821 Ethernet Indicators
Name State Description
Activity Off
Solid/Blinking Green
Not receiving packets
Receiving packets
Duplex Off
Solid Green
Half-Duplex
Full-Duplex
Speed One Blink Green
Two Blink Green
10 Mbps
100 Mbps
Link Off
Solid Green
No link established
Ethernet link is established
Table 8 Cisco 2821 FIPS 140-2 Logical Interfaces
Router Physical Interface FIPS 140-2 Logical Interface
10/100 Ethernet LAN Ports
HWIC Ports
Console Port
Auxiliary Port
ENM Slot
VeNoM S lot
Data Input Interface
10/100 Ethernet LAN Ports
HWIC Ports
Console Port
Auxiliary Port
ENM Slot
VeNoM S lot
Data Output Interface
10/100 Ethernet LAN Ports
HWIC Ports
Power Switch
Console Port
Auxiliary Port
ENM Slot
Control Input Interface
