Cisco 3660 - Installation on Cisco 3660 Routers; Attaching the 23-Inch Rack-Mounting Brackets

4-2
NEBS Level 3 and ETSI Compliance Kit Installation Guide for Cisco 3620, Cisco 3640, and Cisco 3660 Routers
78-5450-06 B0
Chapter 4 Installation on Cisco 3660 Routers
Attaching the 23-Inch Rack-Mounting Brackets
Figure 4-1 23-Inch Bracket Attachment to Cisco 3660 Chassis—Front Panel Forward
Figure 4-2 23-Inch Bracket Attachment to Cisco 3660 Chassis—Rear Panel Forward
26322
Note: The second bracket attaches to the other side of the chassis.
17330
Note: The second bracket attaches to the other side of the chassis.
