4-13
Cisco Secure Router 520 Series Hardware Installation Guide
OL-12892-01
Chapter 4 Router Installation
Connecting the AC Adapter
Figure 4-9 Connecting the AC Adapter
231504
1
2
3
5
4
1 Router 2 AC adapter input jack on the router
3 Power cord 4 AC adapter
5 Electrical outlet
To connect the AC adapter to the router and to an electrical outlet, follow these steps:
Step 1 Connect one end of the power supply cable into the input jack on the router.
Step 2 Connect the other end of the power supply cable to the AC adapter.
Step 3 Plug the power cord of the AC adapter into an electrical outlet.
