Chapter 5 Removal and Replacement Procedures
Removing and Replacing the Power Supply
• Removing a WS-CDC-2500W Power Supply from a Cisco 7609 Router, page 5-21
• Removing a WS-CDC-2500W Power Supply from a Cisco 7613 Router, page 5-24
• Removing a PWR-4000-DC Power Supply from a Cisco 7609 Router or a Cisco 7609-S Router, page
5-26
• Removing a PWR-6000-DC Power Supply from a Cisco 7609 or a Cisco 7609-S Router, page 5-29
• Removing a PWR-6000-DC Power Supply from a Cisco 7613 Router, page 5-37
Removing PWR-950-DC Power Supply from a Cisco 7603 Router
Warning Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Warning Voltage is present on the backplane when the system is operating. To reduce risk of an electric shock,
keep hands and fingers out of the power supply bays and backplane areas.
Follow these steps to remove a DC-input power supply:
Step 1 Verify that power is off to the DC circuit connected to the DC PEM for the power supply you are
removing (Figure 5-8).
Figure 5-8 PEM Location
Step 2
Loosen the captive installation screws on the power supply (Figure 5-9).
