5-52
Cisco 7600 Series Router Installation Guide
OL-4503-24
Chapter 5 Removal and Replacement Procedures
Removing and Replacing the Power Supply
Step 6 Verify power supply operation by checking that the power supply front panel LEDs are in the following
states:
• INPUT OK LED is green
• FAN OK LED is green
• OUTPUT FAIL LED is not lit
If the LEDs indicate a power problem, see the “Identifying Startup Problems” section on page 4-2.
Installing a PWR-2700-DC Power Supply in a Cisco 7606 Router
Warning
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Note If you are installing a PWR-2700-DC power supply in a Cisco 7606 router, you must remove any
preinstalled PEMs. You must also install a blank PEM filler plate for each power supply you are
installing. See Removing and Replacing the PEM, page 5-106.
Follow these steps to install a DC-input power supply:
Step 1 Ensure that the system (earth) ground connection has been made. For ground connection installation
instructions, see the “System Ground Connection” section on page 3-19.
Step 2 Remove the plastic bag attached to the front panel and put aside. This bag contains two plastic terminal
block barriers, two cable ties, and two cable holder covers.
Step 3 Verify that power is off to the DC circuit connected to the power supply you are installing.
Grasp both power supply handles, as shown in Figure 5-56. Slide the power supply into the power supply
bay. Make sure that the power supply is fully seated in the bay.
