Cisco AS5350XM

Continuing Configuration Using the Command-Line Interface
Configuring E1 R2 Signaling
7
Cisco AS5350XM and Cisco AS5400XM Universal Gateways Software Configuration Guide
Step 6
AS5350(config-ctrl-cas)# country country
use-default
Uses defaults for the specified country.
Note To view the parameters for the country (if
the country defaults are the same as ITU
defaults), enter write term.
The default setting for all countries is ITU.
See the “Country Codes for R2 Signaling” section
on page 8 for a list of supported countries.
Step 7
AS5350(config-ctrl-cas)# answer-signal
group-b 6
[or]
AS5350(config-ctrl-cas)# default
answer-signal group-b 6
[or]
AS5350(config-ctrl-cas)# no answer-signal
group-b 6
controller E1 0
clock source line primary
ds0-group 0 timeslots 1-15,17-31 type
r2-analog
r2-compelled
cas-custom 0
country singapore use-defaults
category 2 <--- default category for
singapore
answer-signal group-b 6 <--- default
bxfree
for singapore
AS5350(config-ctrl-cas)# exit
AS5350(config)#
Sets the cas custom command answer signal to
group-b 6.
CAS custom commands include caller-digits,
category, country, unused-abcd, invert-abcd,
metering, ka, kd, dnis-digits, answer-signal, and
nc-congestion
Sets answer-signal group-b to the default ITU
value.
Resets answer-signal group-b 6 to the default
value.
Note The parameters you do not set are
automatically set to the ITU default by the
gateway.
After you configure a country with default
settings, the gateway displays a write term, similar
to the one displayed here.
Exits CAS custom mode and returns to global
configuration mode.
Step 8
AS5350(config)# spe country {country |
e1-default}
Sets the SPE country code or uses the E1 default
(A-law).
Note The gateway must be in idle state (no calls
are active) to execute the SPE country
command.
Note On the Cisco AS5350XM and
Cisco AS5400XM universal gateway,
DS-0 companding law selection is
configured for the entire system rather
than on individual voice ports.
Command Purpose
