Cisco AS5350XM

Understanding Basic Hardware Architecture and Cisco IOS Software
Exploring Cisco IOS Software
7
Cisco AS5350XM and Cisco AS5400XM Universal Gateways Software Configuration Guide
Command Purpose
Step 1
Router> enable
Password: password
Router#
Enters enable mode. Enters the
password. You are in enable mode when
the prompt changes to
Router#.
Step 2
Router# config terminal
Enter configuration commands, one per line. End
with CNTL/Z.
Router(config)#
Enters global configuration mode. You
are in global configuration mode when
the prompt changes to
Router(config)#.
Step 3
Router(config)# controller t1 1/?
<0-1> Controller port number
Router(config)# controller t1 1/0
Specifies the T1 controller that you want
to configure using the controller T1
number global configuration command.
Step 4
Router(config-controller)# ?
Controller configuration commands:
Displays controller configuration
commands.
cablelength
channel-group
default
description
ds0
ds0-group
exit
fdl
framing
help
linecode
loopback
no
pri-group
shutdown
Specify cable length for a
DS1 link
Specify timeslots to
channel-group mapping for an
interface
Set a command to its defaults
Controller specific
description
ds0 commands
Replacement of cas-group
Configure group of timeslots
to a particular signaling
type
Exit from controller
configuration mode
Specify the FDL standard for
a DS1 data link
Specify the type of Framing
on a DS1 link
Description of the
interactive help system
Specify the line encoding
method for a DS1 link
Put the entire T1 line into
loopback
Negate a command or set its
defaults
Configure the specified
timeslots for PRI
Shut down a DS1 link (send
Blue Alarm)
Step 5
Router(config-controller)# ds0-group ?
<0-23> Channel number
Displays the options for the ds0-group
controller configuration command. This
command is used to configure the
channel-associated signaling on a T1
controller.
Step 6
Router(config-controller)# ds0-group 1 ?
timeslots List of timeslots in the ds0-group
Displays the only command (timeslots)
available in ds0-group 1.
