Basic Configuration Using the Command-Line Interface
Configuring T1 and E1 Feature Cards
8
Cisco AS5350XM and Cisco AS5400XM Universal Gateways Software Configuration Guide
5 minute output rate 0 bits/sec, 0 packets/sec
0 packets input, 0 bytes, 0 no buffer
Received 0 broadcasts, 0 runts, 0 giants, 0 throttles
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
0 packets output, 0 bytes, 0 underruns
0 output errors, 0 collisions, 0 interface resets
0 output buffer failures, 0 output buffers swapped out
0 carrier transitions
If you are having trouble, enter the show async status command to check for errors and local and remote
addresses:
AS5400# show async status
Async protocol statistics:
Int Local Remote Qd InPack OutPac Inerr Drops MTU
1/00 42.1.1.1 None 0 0 0 0 0 1500
1/01 192.168.10.100 None 0 0 0 0 0 1500
1/02 192.168.10.100 None 0 0 0 0 0 1500
1/03 192.168.10.100 None 0 0 0 0 0 1500
1/04 192.168.10.100 None 0 0 0 0 0 1500
1/05 192.168.10.100 None 0 0 0 0 0 1500
4/52 192.168.10.100 None 0 0 0 0 0 1500
.
.
.
*6/00 192.168.10.100 34.6.42.1 0 130 50 5 0 1500
*6/01 192.168.10.100 34.6.92.1 0 131 53 5 0 1500
*6/02 192.168.10.100 34.5.92.1 0 130 50 5 0 1500
*6/03 192.168.10.100 34.4.14.1 0 116 40 4 0 1500
.
.
.
*7/102 192.168.10.100 34.1.89.1 0 119 40 4 0 1500
*7/103 192.168.10.100 34.4.34.1 0 118 40 4 0 1500
*7/104 192.168.10.100 34.1.67.1 0 105 40 4 0 1500
7/105 192.168.10.100 None 0 0 0 0 0 1500
*7/106 192.168.10.100 34.4.90.1 0 119 40 4 0 1500
*7/107 192.168.10.100 34.1.42.1 0 119 40 4 0 1500
Rcvd: 25762 packets, 1052214 bytes
0 format errors, 891 checksum errors, 0 overrun
Sent: 8891 packets, 222264 bytes, 0 dropped
Configuring T1 and E1 Feature Cards
On a Cisco AS5350XM or Cisco AS5400XM universal gateway, you can allocate the available channels
for channelized T1 and E1 lines in the following ways:
• Configure all channels to support ISDN PRI.
• If you are not running ISDN PRI, configure all channels to support robbed-bit signaling (also known
as channel-associated signaling).
• Configure all channels in a single channel group.
• Mix and match channels supporting ISDN PRI, channel grouping, and channel-associated signaling
(CAS).
