Cisco AT&T U-verse ISB7005 User Manual

20
Connecting to an SDTV with an S-Video Connector
Cables Used in this Con guration
• 1 S-Video Cable
• 1 Audio Left/Right Cable
WARNING:
Electric shock hazard! Unplug all electronic devices before connecting or
disconnecting any device cables to the receiver.
Receiver
Pr
Pb Y
TO TV
(VIDEO OUT)
S-VIDEO
VIDEO
OUT
AUDIO
OUT
LR
OPTICAL
NETWORK
POWERUSB
CABLE OUT/
ANT OUT
RL
AUDIO
IN
S-VIDEO
IN
RL
AUDIO
OUT
VIDEO
OUT
VIDEO
IN
CABLE IN/
ANT IN
Back of SDTV
T14827

Cisco AT&T U-verse ISB7005 Specifications

General

Manufacturer	Cisco
Model	ISB7005
Category	TV Receiver
Type	Set-top box
Supported Services	AT&T U-verse TV
Video Output	HDMI, Component, Composite
Network Connectivity	Ethernet
Remote Control	Included
Ethernet Port	Yes
Audio Output	Optical
Power Supply	100-240V AC, 50/60Hz
