Supported TechnologyDescriptionSKU ID
LTE bands: 1-5, 7, 8, 12-14, 17, 18-20, 25, 26, 28-30, 32, 38-43, 46, 48, 66, and 71.
FDD LTE 600 MHz (band 71), 700 MHz (bands 12, 13, 14, 17, 28, and 29), 800 MHz
(band 20), 850 MHz (bands 5, 18, 19, and 26), 900 MHz (band 8), 1500 MHz (band
32), 1700 MHz (bands 4 and 66), 1800 MHz (band 3), 1900 MHz (bands 2 and 25),
2100 MHz (band 1), 2300 MHz (band 30), 2600 MHz (band 7).
TDD LTE 1900 MHz (band 39), 2300 MHz (band 40), 2500 MHz (band 41), 2600 MHz
(band 38), 3500 MHz (bands 42 and 48), 3700 MHz (band 43), 5200 MHz (band 46).
United States, Europe, Canada,
Japan, Australia, New Zealand and
Private LTE or U.S. CBRS
P-LTEAP18-GL
Table 7: GNSS Technology Supported
Receive (Rx) Band in MHzRF BandT echnology
1575.42 +/- 1.023GPSGNSS
1597.52 to 1605.92GLONASS
1575.42 +/- 2.046Galileo
1561.098 +/- 2.046BeiDou
Power Supply
IR1800 comes with an external DC power connector. The 4-pin power entry connector (receptacle) is mounted
to the unit. The 4-pin power-entry mating connector (plug) is attached to the receptacle. It is removed during
installation and used to connect to the DC power source, and then reattached to provide power to the unit.
For more information, see Connecting the Router, on page 65.
Serial Ports
IR1800 supports up to two RJ-45 RS232 ports (depending on the model) that conform to EIA-561 standard. The
pinout is shown in the table below.
One RS232 RJ45 serial port (S0) is intended as a DTE port supporting legacy RS232 equipment. The second
serial port (S1) is intended as a DCE port, capable of both RS232 and RS485. RS485 can support full or half
duplex.
The RJ45 pinouts are shown in the following figure and table:
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
22
Product Overview
Power Supply
