Solution Overview
All contents are Copyright © 1992–2007 Cisco Systems, Inc. All rights reserved. This document is Cisco Public Information. Page 13 of 18
Figure 5. Cisco Classic 48-Port 10/100/1000 Module (part number WS-X6148A-GE-TX) with 802.3af PoE
Daughter (floating above) (part number WS-F6K-GE48-AF)
Figure 6. Cisco Classic 96-Port 10/100 802.3af PoE Module (part number WS-X6148X2-45AF)
Figure 7. Cisco Classic 48-Port 10/100 802.3af PoE Module (part number WS-X6148A-RJ-45)
Figure 8. Cisco Classic 48-Port 10/100 802.3af PoE Module, RJ-21 (part number WS-X6148-21AF)
Figure 9. Cisco Classic 96-Port 10/100 (with field upgrade option to 802.3af PoE module) (part number
WS-X6196-RJ-21)
