Cisco PDS2100 Series User Manual

Protect from Exposure to Moisture and Foreign Objects
WARNING: Avoid electric shock and  re hazard! Do not
expose this product to dripping or splashing liquids, rain, or
moisture. Objects  lled with liquids, such as vases, should not
be placed on this apparatus.
WARNING: Avoid electric shock and  re hazard! Unplug
this product before cleaning. Do not use a liquid cleaner or an
aerosol cleaner. Do not use a magnetic/static cleaning device
(dust remover) to clean this product.
WARNING: Avoid electric shock and  re hazard! Never
push objects through the openings in this product. Foreign
objects can cause electrical shorts that can result in electric
shock or  re.
Service Warnings
WARNING: Avoid electric shock! Do not open the cover
of this product. Opening or removing the cover may expose
you to dangerous voltages. If you open the cover, your warranty
will be void. This product contains no user-serviceable parts.
Check Product Safety
Upon completion of any service or repairs to this product, the service
technician must perform safety checks to determine that this product is
in proper operating condition.
Protect the Product When Moving It
Always disconnect the power source when moving the apparatus or
connecting or disconnecting cables.
20110316_Cable_Safety
Cisco PDS2100 Series Set-Top
Model: PDS2100 Series
Manufactured by:
Cisco Systems, Inc.
5030 Sugarloaf Parkway
Lawrenceville, Georgia 30044 USA
Telephone: 770 236-1077
Notice to Consumers
The Cisco® PDS2100 Series Set-Top receives digital signals from your
service provider and delivers programs in standard de nition (SD) and
high de nition (HD) formats (720p and 1080i).
You must have an HDTV to display HD programming. Programming
must originate in HD format and be broadcast in HD format.
Please read the safety instructions before connecting your set-top.
Connecting to an SDTV with RCA Cable
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its a liates in the U.S. and other countries. To view a list
of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks.
The terms HDMI and HDMI High-De nition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks
of HDMI Licensing LLC in the United States and other countries.
Other third party trademarks mentioned are the property of their respective
owners. The use of the word partner does not imply a partnership
relationship between Cisco and any other company. (1110R)
© 2013 Cisco and/or its a liates. All rights reserved.
April 2013 Part Number 78-20808-01 Rev B0
Cisco Systems, Inc. http://www.cisco.com
170 West Tasman Drive Tel: 408 526-4000
San Jose, CA 95134-1706 USA 800 553-6387
Connecting to an HDTV with HDMI Cable
Open Source GNU GPL Statement
Cisco PDS2100 Series set-tops contain(s), in part, certain free/open
source software (“Free Software”) under licenses which generally make
the source code available for free copy, modi cation, and redistribution.
Examples of such licenses include all the licenses sponsored by the Free
Software Foundation (e.g. GNU General Public License (GPL), GNU Lesser
General Public License (LGPL), Berkeley Software Distribution (BSD), the
MIT licenses and di erent versions of the Mozilla and Apache licenses).
To  nd additional information regarding the Free Software, including a
copy of the applicable license and related information, please go to: (i)
for North America http://www.cisco.com/web/consumer/support/
open_source.html, or (ii) for outside North America http://www.cisco.
com/web/consumer/support/open_source.html#~international. Once
at the site, search for the product listing and click on the related items
identi ed. If you have any questions or problems accessing any of the links,
please contact: spvtg-external-opensource-requests@cisco.com.
T15922
CABLE OUT ETHERNETR
L S/PDIF
CVBS USB IR INCABLE IN
To Wall Jack
Back of Set-Top
Back of
SDTV
RF IN
SCART VIDEO IN
RF OUT
RL
AUDIO
IN
VIDEO
IN
Y
P
B
PR
RL
AUDIO
OUT
VIDEO
OUT
Cable Input
Back of Set-Top
ETHERNETR
L S/PDIF
CVBS USB IR IN
CABLE OUTCABLE IN
Cable Input
Back of
HDTV
ANT (75 )
INOUT
ANT-1
HD 2
Y
OUT
ANT-2
PB
PR
L
R
VIDEO
L/
MONO
R
L/
MONO
R
AUDIO
IN
S-VIDEO
VIDEO
AUDIO
SCART VIDEO OUT
SCART VIDEO IN
HDMI
IN
AUDIO
IN
AUDIO IN
D
VI
/
HD
CP
L
R
IN
HD 1
Y
PB
PR
L
R
AUDIO
To Wall Jack
T15923
