Cisco Webex Desk Pro Installation Guide

2 3
3 m / 9.8 ft
1.5 m / 4.9 ft ×2
×2
1.5 m / 4.9 ft 1.8 m / 5.9 ft
Ordered separately
Commandés séparément / Separat bestellt / Ordinabili separamente / Pedidos por separado /
Encomendados em separado
What’s in the box
Composants fournis / Verpackungsinhalt / Contenuto della confezione /
Descripción general de los pasos / Conteúdo da caixa
• Width
Largeur / Breite / Larghezza / Ancho /
Largura
63 cm / 24.8 in.
• Height
Hauteur / Höhe / Altezza / Altura / Altura
51 cm / 20.1 in.
• Depth
Profondeur / Tiefe / Profondità / Profundidad
/ Profundidade
7.5 cm / 3 in.
• Weight
Poids / Gewicht / Peso / Peso / Peso
11.6 kg / 25.6 lb.
This equipment is not suitable for use in locations where children are likely to be present.
Cet équipement ne convient pas à une utilisation dans un environnement où des enfants sont
susceptibles d'être présents.
Dieses Gerät ist nicht für den Einsatz an Orten geeignet, an denen sich wahrscheinlich Kinder aufhalten.
Questa apparecchiatura non è adatta per l'uso in ambienti frequentati da bambini.
Este equipo no es apto para usar en lugares donde es probable que haya niños presentes.
Este equipamento não é adequado para utilizar em locais onde é provável que se encontrem crianças.
WARNING Do not cover the desk device
To prevent overheating, the desk device should not be covered or placed in a niche.
ATTENTION à ne pas couvrir la barre multimédia
Pour éviter toute surchauffe, la barre multimédia ne doit pas être couverte ou placée dans une alcôve.
WARNUNG: Die Medienleiste darf nicht verdeckt werden
Um ein Überhitzen zu vermeiden, darf die Medienleiste nicht abgedeckt oder in einer Nische aufgestellt
werden.
ATTENZIONE Non coprire la barra multimediale
Per evitare il surriscaldamento, la barra multimediale non deve essere coperta o posta in una nicchia.
ADVERTENCIA No cubra la barra multimedia
Para evitar el sobrecalentamiento, la barra multimedia no debe cubrirse ni colocarse en un hueco.
AVISO Não cobrir a barra multimédia
Para evitar o sobreaquecimento, não deve cobrir a barra multimédia nem colocá-la num nicho.
Dimensions
Dimensions / Maße / Dimensioni / Dimensiones físicas / Dimensões

Cisco Webex Desk Pro Specifications

General

Product type	Group video conferencing system
Product color	Silver
Number of persons	- person(s)
Megapixel	12 MP
Sensor type	CMOS
Gain control type	Auto
Image sensor size	1/2.8 \
Vertical field of view	59 °
Horizontal field of view	71 °
Supported video modes	1080p, 1440p, 2160p
Video formats supported	H.263, H.264
Resolution at capture speed	1920x1080@60fps, 3840x2160@30fps, 3840x2160@60fps
Voice codecs	AAC, G.711, G.722, G.722.1, G.729, OPUS
Frequency range	60 - 20000 Hz
RMS rated power	14 W
USB 2.0 ports quantity	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	27 \
Touchscreen type	Capacitive
Display brightness	300 cd/m²
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	89 °
Telepresence	-
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 90 %
Power consumption (max)	200 W
Country of origin	China
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	75 mm
Width	630 mm
Height	510 mm
Weight	11600 g
Package width	779.78 mm
Package height	218.44 mm
Package weight	15960 g
