Supervisor Engine 32
Uplink ports (PORT 1
through PORT
9)
• The WS-SUP32-GE-3B has nine uplink ports: Eight 1000BASE-X SFP
ports and one 10/100/1000BASE RJ-45 port. All nine uplink ports can
be used at one time.
Note The eight 1000BASE-T or 1000BASE-X uplink ports require SFP
transceivers to be installed.
• The WS-SUP32-10GE-3B has three uplink ports: two 10-Gigabit
XENPAK ports and one 10/100/1000BASE RJ-45 port. All three ports
can be used at one time
Note The two 10-Gigabit uplink ports require XENPAK transceivers to be
installed.
Note In chassis configurations where there are redundant supervisor
engines installed, the uplink ports on the supervisor engine that is in
standby mode are fully functional.
Each uplink port has a LINK LED associated with it.
Universal Serial Bus (USB)
port
Two USB 2.0 ports are provided. Currently, they are not enabled.
Uplink port queue structure
(Tx/Rx)
1p3q8t/2q8t
Buffer size • WS-SUP32-GE-3B:
–
Total buffer size—10 MB
–
Rx/Tx buffer size—5 MB/5 MB
• Sup32-10GE-3B:
–
Total buffer size—17.7 MB
–
Rx/Tx buffer size—9.6 MB/8.1 MB
Pluggable transceivers
supported
• WS-SUP32-GE-3B—1-GB SFP transceivers are supported in eight
uplink ports.
• WS-SUP32-10GE-3B—10-GB XENPAK transceivers are supported in
the two uplink ports.
Note See Appendix A for a list and a description of the SFP and XENPAK
transceivers that are supported.
Hardware-based forwarding
engine (Policy Feature Card)
The PFC3B is installed on all versions of Supervisor Engine 32
Note The WS-F6K-PFC3A Policy Feature Card 3A (PFC3A) and the
WS-F6K-PFC3BXL Policy Feature Card
3BXL (PFC3BXL) are not
supported.
Multilayer Switch Feature Card
(MSFC) daughter card version
installed
MSFC2A
Table 2-6 Supervisor Engine 32 Features (continued)
Feature Description
