Supervisor Engine 2T
Uplink port queue structure • 1000BASE-X (uplink ports 1, 2, and 3)
–
Tx—1p3q4t
–
Rx—2q4t
• 10GBASE-X (uplink ports 4 and 5)
–
With ports 1, 2, and 3 enabled: Tx—1p3q4t, Rx—2q4t
–
With ports 1, 2, and 3 disabled: Tx—1p7q4t, Rx—8q4t
• 1 port group
Pluggable transceivers
supported
• Supports SFP 1000BASE-X transceivers in Ports 1, 2, and 3.
• Supports X2 10-GBASE-X transceivers in Ports 4 and 5.
Note For additional information about SFP and X2 transceiver support,
see the compatibility matrices listed on this page:
http://www.cisco.com/en/US/products/hw/modules/ps5455/produc
ts_device_support_tables_list.html
Also see Appendix A for descriptions of the X2 and SFP
transceivers.
Hardware-based forwarding
engine (Policy Feature Card)
• VS-S2T-10G—PFC4 (VS-F6K-PFC4)
• VS-S2T-10G-XL—PFC4XL (VS-F6K-PFC4XL)
Multilayer Switch Feature Card
(MSFC) daughter card version
installed
MSFC5 (VS-F6K-MSFC5)
Table 2-22 Supervisor Engine 2T Features (continued)
