Supervisor Engine 2T
LINK (SFP UPLINK) Each of the three SFP uplink ports has a LINK LED associated with
it. The LINK LED indicates the link status of the corresponding
port.
• Green—The port is active (the link is connected and
operational).
• Flashing orange—The port failed diagnostics and is disabled.
• Orange—The port is disabled.
• Red—The supervisor engine is resetting; an overtemperature
condition has occurred.
Note If the supervisor engine fails to download code and
configuration information successfully during the initial
reset, the LED stays red; the supervisor engine does not
come online.
• Off—The port is not active or the link is not connected.
MANAGEMENT port The 10/100/1000 management port has an green LED associated
with it.
• Green—The port is active (the link is connected and
operational).
• Off—The port is not active or the link is not connected.
LINK (10GE UPLINK) Each of the two 10GE uplink ports have a link LED associated with
it.
• Green—The port is active (the link is connected and
operational).
• Flashing orange—The port failed diagnostics and is disabled.
• Orange—The port is disabled.
• Red—The supervisor engine is resetting; an overtemperature
condition has occurred.
Note If the supervisor engine fails to download code and
configuration information successfully during the initial
reset, the LED stays red; the supervisor engine does not
come online.
Off—The port is not active or the link is not connected.
Table 2-24 Supervisor Engine 2T Front Panel Status LEDs (continued)
LED Color and Meaning
