Citizen CL-S300 - Page 22

3. Pass the dispenser cable
through the opening as
shown in the illustration.
4. Fit the label dispenser in
the recess provided.
5. Turn the printer upside
down and take out the
screws to open the
cover.
6. Open the cover on the
bottom of the printer to
access the motherboard.
7. Tighten the screws to
secure the label
dispenser.
20
