Number Value Note – Description
12 60 N.m Access plug to the high-pressure pump pinion.
Use a new O-ring.
13 — Oil pressure controller.
For unspecified tightening torques, refer to the section entitled: "Tightening torques".
CAUTION
Contact with very hot liquids or machine parts.
Risk of burns
► Wear suitable protective clothing.
► Allow liquids or machine parts to cool.
► Follow the instructions in the operator's manual.
Environment!
Lubricants and fuel are harmful to the environment.
Pollution
► Collect lubricants and fuel in appropriate containers; store and dispose of them in accordance with the
regulations in force.
WARNING
Lifting heavy components.
Risk of death or serious injury.
– Use lifting equipment that will support the load.
– Use reliable lifting equipment.
– Placer the lifting equipment on the appropriate locations.
Preparation for work
Consumables to be used:
- Sealing and glue product:
Loctite (515) – 60 0571 950 5.
Special tool
