Nitrogen Generator NiGen GC Nigen MICRO
7
3.2.2. Compressed air supply, specifications
(***) for further details on the air quality, see the specifications for Class 1-4-1,
ISO 8573-1
3.2.3. Electrical requirements
3.2.4. Pneumatic connections
3.2.5. Electrical connections
Pressure
minimum 8 bar 116 psi
maximum 10 bar 145 psi
Capacity
NiGen GC 6 Nl/min 6 slpm
NiGen GC HC 6 Nl/min 6 slpm
NiGen MICRO 12 Nl/min 12 slpm
Particulates: maximum concentra-
tion of particles of diameter less
than 0.1 µm (***)
less than 0.1 mg/m³
Oil concentration less than 0.01 mg/m³
Humidity dewpoint under pressure less than 3°C
NiGen GC 115-230 V~ (±10%), 1 ph, 50-60Hz;
50W
NiGen GC HC
115 V~ (±10%); 60Hz; 1ph; 200W
or
230 V~ (±10%) 50Hz; 1 ph; 200W
NiGen MICRO
115-230 V~ (±10%), 1 ph, 50-60Hz;
50W
Nitrogen outlet G 1/8" female
Compressed air supply G 1/8" female
Power supply IEC320
CAN bus IN; CAN bus OUT RJ45
