Description of the generator
6
3.
Description of the generator
3.1.
Equipment supplied
Unless otherwise agreed, the consignment includes:
• n°1 nitrogen generator model NiGen;
• n°1 CD user’s manual;
• n°1 applicable declarations of conformity of tank and safety valve;
• n°1 cable for the electrical mains;
• n°4 self-tapping screws;
• n°2 elastic spline;
• n°2 check pin;
• n°1 anchor plate;
• n°2 fitting for the connection of the plastic tube external diameter 6mm;
• n°1 fitting for the connection of the copper tube external diameter 1/8”.
3.2.
Technical specifications
3.2.1.
Nitrogen
(*) the flow rate is given at 20°C and 1 atm
(**) purity referred to residual oxygen
Maximum flow rate (*)
NiGen GC 0.5 Nl/min 0.5 slpm
NiGen GC HC 0.5 Nl/min 0.5 slpm
NiGen MICRO 4 Nl/min 4 slpm
Pressure
settable from 0 to
6 bar
settable from 0 to
87 psi
Purity (**)
NiGen GC up to 99.999 %
NiGen GC HC up to 99.999 %
NiGen MICRO up to 99.5 %
